How to Build Knowledge Graphs With LLMs (python tutorial)

Intro (0s)

• Discussed how graph databases and large language models (LLMs) can generate knowledge graphs from unstructured data.
• LLMs can be used to identify entities and relationships and interact with the database through a chat interface.
• Knowledge graphs have advantages over vector search in some applications.
• The video was well-received, prompting detailed explanations on building the system with code.
• The tutorial includes a step-by-step coding guide.

Environment overview (1m3s) & Neo4J & OpenAI Configuration (2m47s)

• Data consists of profiles, project briefs, and Slack messages linked to the same people.
• Data in JSON format and markdown files, generated using ChatGPT.
• An .env file holds secrets and credentials for the OpenAI API and Neo4J database.
• Python libraries required are listed in requirements.txt.
• Code execution is done in a Jupyter Notebook.
• Configuration parameters for OpenAI API include API key, endpoint, and version.
• Neo4J requirements include endpoint URL, username, password, and database setup.
• Azure is used to manage OpenAI models, with deployment names and keys gathered for use.
• Neo4J Aura's hosted setup allows for instance creation and database connection setup.
• Important to note down Neo4J credentials upon instance creation as the password is only shown once.

Helper functions (7m50s)

• A function is defined to facilitate calling the OpenAI API with a system message/prompt and content.
• The function uses the OpenAI Library, setting a maximum of 15,000 tokens and a temperature of zero.
• System messages and user messages structure the request, with results filtering for the final response.
• The function simplifies obtaining the text response from the OpenAI API.

Identifying entities and relationships in data (9m15s)

• Introduced a function to extract entities and relationships from a folder of files, returning a JSON object.
• The function receives a folder name and prompt templates, and processes all files in a specified data directory.
• It initializes a list to save results and loops through each file, stripping whitespace from the contents.
• Each file type has a dedicated prompt template, which includes placeholder values for file contents.
• A generic system message is defined to provide context for the model, such as "You are helpful IT project and accounts management experts".
• Results from the language model are appended to a list, and exceptions are printed with the file name.
• A timer is implemented to track processing duration for each folder.
• File prompts contain detailed instructions for the language model to identify entities, such as projects, technologies, and clients, and their attributes.
• The model extracts relationships based on document context and produces a JSON output with entities and relationships lists.
• Testing and error handling for rate limits are performed, with solutions such as requesting limit increases or adding delays between requests.

Function Implementation Details

• The function uses language model API calls to interpret each document.
• A project brief prompt instructs the model to extract entities with attributes and generate relationships, expecting a JSON result format.
• Entity IDs are created using lowercase names with special characters removed, though this approach is noted as not reliable for production.
• Technologies are identified with detail to distinguish specific instances.
• Clients and industries are inferred from document context.
• Relationships are structured based on entity co-mention within a document.
• Adjustments to the function include renaming variables for clarity, fixing mistakes, and ensuring JSON objects are correctly read into results.
• Rate limits are managed by adding delays between API requests.
• Results include node types, IDs, relationships, and summaries formatted as per instructions.

Generating Cypher Statements (21m49s)

• The function converts JSON into Cypher statements for Neo4j.
• Cypher statements are used to create entities and relationships within the database.
• The function loops through JSON objects to extract label and ID keys, while special characters in IDs are removed.
• Nodes have properties, such as a project entity's summary, which are added dynamically along with other key-value pairs into the Cypher statement.
• The merge keyword is used in Cypher to avoid duplicate entities during multiple executions.
• Attributes for nodes are created with oncreate set.
• The function writes the generated Cypher statements into a text file.
• Relationship loops extract source node ID, relationship type, and target node ID, using a pipe character as a separator.
• A relationship Cypher statement defines the relationship between two nodes using their IDs and types.
• The function appends Cypher statements to a list and returns the combination of entity and relationship statements.

Running the full pipeline (33m20s)

• A pipeline function runs all defined functions in sequence to bring together the extraction and database insertion processes.
• The function processes a dictionary that maps folder names to prompt templates.
• extract entities and relationships function is called for each item, returning a list of entities and relationships which get extended into one comprehensive list.
• generate Cypher function takes the list in JSON format and outputs Cypher statements which are then executed in the database through a GDs execute query method, with the results also written to a file.
• During execution, errors are caught and logged into a failure file.
• After execution, the database is checked in the Neo4j workspace to confirm the presence of nodes and relationships which indicates success in knowledge graph creation.
